Carbon Fumapem AM-40 - PBI Copolymer

Get a Price/Quote

Carbon Fumapem AM-40 - PBI Copolymer Specification

Material
PBI Copolymer Membrane

Application
Electrochemical Devices such as Fuel Cells, Electrolyzers, and Redox Flow Batteries

Chemical Composition
Polybenzimidazole (PBI) Copolymer

Shape
Membrane / Flat Sheet

Hardness
74 Shore A

Density
1.35 Gram per cubic centimeter(g/cm3)

Operating Temperature Range
Up to 180C

Proton Conductivity
High (optimized for proton exchange)

Dimensional Stability
High, minimal swelling

Ionic Conductivity
0.10 S/cm (in acid solution)

Water Uptake
55% (in acid solution)

Shelf Life
12 months (under specified storage conditions)

Storage Conditions
Store at room temperature, dry and dark place

Color
Light Yellow

Customization
Available in other thicknesses upon request

Elongation at Break
>15%

Tensile Strength
>22 MPa

Thickness
40 microns

Carbon Fumapem AM-40 - PBI Copolymer Trade Information

Payment Terms
Paypal

Delivery Time
15 Days

Main Export Market(s)
Asia

Main Domestic Market
All India

About Carbon Fumapem AM-40 - PBI Copolymer

Brand:FuMA-Tech
Product Code:5041632

FumapemAM-40 is a non-reinforcedPolybenzimidazole Copolymermembranedesigned for use in High-Temperature Proton Electrolyte Fuel Cells (HT-PEMFC).The polymer backbone for this HT-PEMFC membrane is categorized as a hydrocarbonpolymer material.

FumapemAM-40 membrane comes in either a 10cm x 10cm or 20cm x 30cm size sheet. Themembrane is the brown foil delivered in dry form.

Fumatechmembranes are highly sensitive to differences in humidity and moisture content.Therefore the membranes can vary +/- 0.5cm from the original cut sizes. Alsodue to this sensitivity the manufacturer expects wrinkles to form, howeversoaking the membranes in deionized water will return the membranes to the fullsize planar state according to the manufacturer.

FumapemAM-40 Features:

Applications:High-Temperature PEM Fuel Cell (HT-PEMFC).
Thickness: 40 micrometers (1.57 mil)
Sizes: 10cm x 10cm, 20cm x 30cm

Handling:

Keep membrane package closed / sealed when unused. Store,handle and process the membrane in a clean and dust-free area. Use only new andsharp knives or blades, when cutting the membrane. Always wear protectivegloves when handling the membrane. Handle with care, be sure not to puncture,crease or scratch the membrane, otherwise leaks will occur. All surfaces incontact with the membrane during handling, inspection, storage and mountingmust be smooth and free of sharp projections.

Doping with Phosphoric AcidRecommendation:

Put the membrane sample in 85 wt % H3PO4 at temperaturesbetween 90C and 160C for at least 1 hour. Membranes must be covered byphosphoric acid. Membranes will expand when subject to doping process.

If you have any concerns about storage, chemicalstability, pre-treatment or before proceeding, please feel free to contact usfor further information.

Long Term Storage:

The membrane can be stored dry for anunlimited amount of time. However, the membrane has to be conditioned (washedand rinsed) prior to use.

Advanced Material for Electrochemical Applications

Fumapem AM-40 leverages the robust properties of PBI copolymer to provide a durable and reliable solution for modern electrochemical devices, including fuel cells, electrolyzers, and redox flow batteries. This membrane excels in challenging environments, thanks to its remarkable chemical, tensile, and dimensional stability, even at high operating temperatures.

Optimized Performance and Customization

Designed to deliver high proton conductivity and minimal swelling, Fumapem AM-40 ensures superior efficiency and consistency during device operation. The membrane can be tailored in thickness upon request, making it adaptable to a broad range of industrial specifications and research requirements.

FAQ's of Fumapem AM-40 - PBI Copolymer:

Q: How should Fumapem AM-40 be stored to ensure its maximum shelf life?

A: Fumapem AM-40 should be stored at room temperature in a dry and dark location. Following these conditions helps maintain its quality and guarantees a shelf life of up to 12 months.

Q: What are the primary applications of the Fumapem AM-40 membrane?

A: Fumapem AM-40 is primarily designed for use in electrochemical devices, such as fuel cells, electrolyzers, and redox flow batteries, where high proton conductivity and chemical stability are required.

Q: When is it beneficial to choose Fumapem AM-40 for a project?

A: Fumapem AM-40 is ideal when projects demand high thermal and chemical stability, especially under acidic, oxidative, or high-temperature conditions (up to 180C), ensuring long-term durability and performance.

Q: Where can customers purchase Fumapem AM-40 membranes in the United States?

A: Fumapem AM-40 is available through authorized distributors, manufacturers, retailers, suppliers, and traders across the United States. For specific ordering information, it is best to contact an official supplier directly.

Q: What makes Fumapem AM-40 stand out in terms of durability and efficiency?

A: The membrane's construction from PBI copolymer imparts exceptional toughness, evidenced by its >22 MPa tensile strength and >15% elongation at break. Its high dimensional stability and resistance to acidic and oxidative environments ensure reliable and long-lasting device operation.

Q: How does customization work for Fumapem AM-40 membranes?

A: Customers can request Fumapem AM-40 in different thicknesses to match their technical requirements. This adaptability allows for seamless integration into various device architectures and research projects.
